Light bulbs Halogen lamps

G9-20W STAR

Halide light source G9 STAR

G9-20W STAR

Product code: 18420 logo KANLUX

Kanlux G9 STAR is a halogen bulb with G9 light bulb base.

Rated voltage [V] 220-240 AC

On-mode power Pon [W] 20

Useful luminous flux of the light source Φuse [lm] 235

Colour temperature [K] 2700

Cap G9

Rated lamp-service life [h] 2000

Scroll down to the full specification

Ask a question

Compare

Go to dictionary

Do you want to maintain consistency?

See products from the same series

Halide light source G9 STAR G9-33W STAR Product code: 18421

Compare

Halide light source G9 STAR G9-48W STAR Product code: 18422

Compare

Halide light source G9 STAR G9-60W STAR Product code: 18423

Compare

Specification

General description

EAN13 5905339184207

Material non-corrosive metals alloy

Lampshade material glass

Weight and dimensions

Height [mm] 43

Diameter [mm] 14

Depth [mm] 14

Weight 3g

Sales unit piece

Outer box 50

Energy class

Technical data

Rated voltage [V] 220-240 AC

Rated frequency [Hz] 50

Rated power [W] 20

On-mode power Pon [W] 20

Show more ▾

Claim of equivalent power [W] 23

Cap G9

Total rated luminous flux [lm] 235

Useful luminous flux of the light source Φuse [lm] 235

Useful luminous flux of the light source Φuse [lm] in sphere (360°)

Rated lamp-service life [h] 2000

Colour temperature [K] 2700

Colour-rendering index Ra 100

Colour temperature Warm white

Lighting angle [°] 360

Number of on/off cycles ≥8000

Energy consumption in on-mode (kWh/1000h) 20

Mercury content no, no

Lamp designed for dimming

Lamp rated current [mA] 87

Luminous efficiency of the lamp [lm/W] 12

Materials

Specification

Family card PDF, Size: 251.7 KB

Technical card PDF, Size: 450.44 KB

Handling and installation

Vertical energy label PDF, Size: 925.14 KB

Approvals and certificates

Declaration of Conformity PDF, Size: 740.83 KB
