BRAVO DRIVER 40W

LED power supply unit BRAVO DRIVER

BRAVO DRIVER 40W

Product code: 28026 logo KANLUX

Rated voltage [V] 220-240 AC

Maximum power [W] 40

IP class 20

Colour white

Scroll down to the full specification

Ask a question

Compare

Go to dictionary

Do you want to maintain consistency?

See products from the same series

LED power supply unit BRAVO DRIVER BRAVO DRIVER 36W Product code: 28025

Compare

Together better

Select complementary products

Recessed-mounted LED panel BRAVO S BRAVO S 40W6060NW W Product code: 28010

Compare

Recessed-mounted LED panel BRAVO S BRAVO S 40W12030NW W Product code: 28022

Compare

Specification

General description

EAN13 5905339280268

Colour white

Material plastic

Weight and dimensions

Weight 130g

Sales unit piece

Outer box 6

Technical data

Rated voltage [V] 220-240 AC

Rated frequency [Hz] 50

Colour white

Supply-cord type direct current

Show more ▾

Rated current [A] 0,25

λ 0,95

Maximum power [W] 40

Input voltage - PRI [V] 220-240

Output voltage - SEC [V] 30-42

Output current - sec [ma] 1050

Tc [°C] 75

Maximum temperature Ta [°C] 25

Thermal protection 110°C

Short-circuit protection 1

Overload protection

Overvoltage protection 1

Possibility of installation on a normally flammable surface yes

IP class 20

Class of protection against electric shock II

Connection type Terminal block

Range of sections of wires used [mm2] 0,75÷1

Compatible with a dimmer no

Materials

Specification

Family card PDF, Size: 329.28 KB

Technical card PDF, Size: 136.58 KB

Approvals and certificates

Declaration of Conformity PDF, Size: 892.05 KB
