OS-L8D-NW-RST-W-N3

Surface-mounted LED office fixture OFIS RST LED N3

OS-L8D-NW-RST-W-N3

Product code: 35863 logo Kanlux Factory

A series of fixtures for professionals from the Kanlux Factory, which combines functionality and aesthetics. Thanks to very good lighting parameters, OFIS RST LED luminaires allow you to create energy-saving and modern lighting systems.

Scroll down to the full specification

Ask a question

Compare

Go to dictionary

Specification

General description

Warranty [years] 5

EAN13 5905339358639

Colour white

Enclosure material Metal

Lampshade material plastic

Weight and dimensions

Height [mm] 35

Width [mm] 300

Length [mm] 1200

Weight 4300g

Sales unit piece

Outer box 1

Additional features

5 years Warranty under the terms of the warranty statement, available on our website

Technical data

Rated voltage [V] 220-240 AC

Rated frequency [Hz] 50

Shade type louvre

Show more ▾

Colour white

Maximum power [W] 31

Integrated LED light source

Luminous flux of the light fitting [lm] 4300

Luminous efficiency of the lamp [lm/W] 139

Lighting angle [°] 80

Number of on/off cycles ≥30000

Service life [h] 50000

Luminous flux retention factor at the end of rated service life L90B10

Colour temperature [K] 4000

Colour uniformity [SDCM] ≤3

Colour-rendering index Ra 80

Lamp-ignition time [s] ≤0,5

Lamp-heating time [s] ≤1

Diode type LED SMD

Compatible with a dimmer no

Colour temperature white

Class of protection against electric shock I

IP class 20

Ambient temperature range to which the product can be exposed 5÷25

Place of assembly ceiling mounted

The product is not suitable to be covered with a heat-insulating material

Connection type Self-clamping block

Range of sections of wires used [mm2] 1,5÷2,5

Minimum distance from the illuminated object 0,5m

beam angle x [°] 80

Materials

Specification

Family card PDF, Size: 515.21 KB

Technical card PDF, Size: 507.58 KB

Photometric data

File ldt - OS-L8D-NW-RST-W-N3 LDT, Size: 8.8 KB

File ies - OS-L8D-NW-RST-W-N3 IES, Size: 8.57 KB

Approvals and certificates

Declaration of Conformity PDF, Size: 92.14 KB
