Kanlux Oświetlenie

CV power supply unit LC

LC 200W 24V IP67 UNV

Product code: 33424 logo KANLUX


Scroll down to the full specification

Do you want to maintain consistency?

See products from the same series

Specification

General description
EAN13 9006210737867
Weight and dimensions
Weight 1098g
Sales unit piece
Outer box 1
Additional features
  • The power supply  unit is not designed to work without load.
Technical data
Rated voltage [V] 220-240 AC
Rated frequency [Hz] 50
Supply-cord type constant-voltage
Maximum power [W] 200
Show more ▾
Input voltage - PRI [V] 220-240
Output voltage - SEC [V] 24 DC
Output current - sec [ma] max 8333
Thermal protection 90°C
Short-circuit protection 1
Overload protection
IP class 67
Range of sections of wires used [mm2] 0,5-1,5

Materials
